Multiplexer has a set of interfaces for a variety of multi-function adapter plates. It supports USB, TTL, RS232, RS485 interfaces between the system conversions. What’s more powerful is that it also supports one input multiple outputs, which greatly facilitates the communication between various controllers.

Tip: Multiplexer board is divided into A and B interfaces. The signal can be convertered between A and B. The signal in the same interface can’t be convertered thus only one sender in the same interface, but it allows to have multiple receivers.

Features:

1. Single chip USB to asynchronous serial data transfer interface.
2. Unique USB FTDIChip-ID™ feature.
3. Configurable CBUS I/O pins.
4. Data transfer rates from 300 baud to 3 Mbaud (RS422, RS485, RS232 ) at TTL levels.
5. Entire USB protocol handled on the chip. No USB specific firmware programming required.

Package Includes:

1 x DFRobot Multi USB / RS232 / RS485 / TTL Converter
