5d67b4a1c3d0f20c837ba284 GSM SIM800C Modem with Antenna https://www.componentstores.com/s/59c9e4669bd3e7c70c5f5e6c/ms.products/5d67b4a1c3d0f20c837ba284/images/5d67b4a1c3d0f20c837ba28a/5d67b45a17f6031eafff75cb/5d67b45a17f6031eafff75cb.jpg

Description

GSM SIM800C Modem with Antenna Module’s baud rate is configurable from 9600-115200 through AT command. The GSM GPRS Modem is having internal TCP/IP stack to enable you to connect with internet via GPRS. It is suitable for SMS, Voice as well as DATA transfer application in M2M interface. The onboard Regulated Power supply allows you to connect wide range unregulated power supply. Using this modem, you can make audio calls, SMS, Read SMS, attend the incoming calls and internet etc through simple AT commands.

The Modem is built with Quad-Band GSM/GPRS engine-SIM800C from SIMCOM, works on frequencies 850/ 900/ 1800/ 1900 MHz. The Modem is populated with DB9 Female connector so as to directly connect with computer or other RS232 Compatible devices. MAX3232 from MAXIM Semiconductor is used for the RS232 Level conversion. The modem will work with 5-12V DC, which can be fed either through onboard 2 Pin RMC connector or DC Jack. The modem is powered by High Current Low Dropout Linear Voltage regulator so as to withstand high surge current requirement (may rise up to 2A)

General features of SIM800C Module
  1. Quad-band 850/900/1800/1900MHz
  2.  GPRS multi-slot class 12/10
  3. GPRS mobile station class B
  4. Compliant to GSM phase 2/2+
    1. Class 4 (2 W @ 850/900MHz)
    2. Class 1 (1 W @ 1800/1900MHz)
  5.  Control via AT commands
  6. (3GPP TS 27.007, 27.005 and SIMCom enhanced AT Commands)
  7. Supply voltage range 3.4 ~ 4.4V
  8. Low power consumption
Applications:
  1. Industrial automation.
  2. GPRS based data logging.
  3. GPRS and GPS application.
  4. Home automation.
  5. Health monitoring.
  6. Agriculture automation.
  7. Vehicle tracking.
  8. Remote monitoring and controlling.
  9. GPRS based Weather report logging.
  10. GSM GPRS based Security alert.
  11. GPRS based remote terminal for file transfer.
  12. IVRS.
  13. Bulk SMS sending etc.

Specifications and Features:

  1. Quad-Band 850/900/1800/1900MHz.
  2. RS232 interface for direct communication with computer or MCU kit.
  3. Configurable baud rate.
  4. ESD Compliance.
  5. With slid in SIM card tray.
  6. With Stub antenna and SMA connector.
  7. Input Voltage: 12V DC.
  8. High-quality PCB FR4 Grade with FPT Certified.
 TT-RKK-235870
in stock INR
GENERIC
1 1
GSM SIM800C Modem with Antenna

GSM SIM800C Modem with Antenna

Sku: TT-RKK-235870
Be the first to review this product
Product Enquiry
Contact Seller Contact Seller
Sold By: tenettech
Features
  • Shipping in 10-12 Working days
  • http://cdn.storehippo.com/s/59c9e4669bd3e7c70c5f5e6c/ms.products/5d67b4a1c3d0f20c837ba284/images/5d67b4a1c3d0f20c837ba285/5d67b41e4a4d100d1dc350cc/5d67b41e4a4d100d1dc350cc.jpg

Description of product

Description

GSM SIM800C Modem with Antenna Module’s baud rate is configurable from 9600-115200 through AT command. The GSM GPRS Modem is having internal TCP/IP stack to enable you to connect with internet via GPRS. It is suitable for SMS, Voice as well as DATA transfer application in M2M interface. The onboard Regulated Power supply allows you to connect wide range unregulated power supply. Using this modem, you can make audio calls, SMS, Read SMS, attend the incoming calls and internet etc through simple AT commands.

The Modem is built with Quad-Band GSM/GPRS engine-SIM800C from SIMCOM, works on frequencies 850/ 900/ 1800/ 1900 MHz. The Modem is populated with DB9 Female connector so as to directly connect with computer or other RS232 Compatible devices. MAX3232 from MAXIM Semiconductor is used for the RS232 Level conversion. The modem will work with 5-12V DC, which can be fed either through onboard 2 Pin RMC connector or DC Jack. The modem is powered by High Current Low Dropout Linear Voltage regulator so as to withstand high surge current requirement (may rise up to 2A)

General features of SIM800C Module
  1. Quad-band 850/900/1800/1900MHz
  2.  GPRS multi-slot class 12/10
  3. GPRS mobile station class B
  4. Compliant to GSM phase 2/2+
    1. Class 4 (2 W @ 850/900MHz)
    2. Class 1 (1 W @ 1800/1900MHz)
  5.  Control via AT commands
  6. (3GPP TS 27.007, 27.005 and SIMCom enhanced AT Commands)
  7. Supply voltage range 3.4 ~ 4.4V
  8. Low power consumption
Applications:
  1. Industrial automation.
  2. GPRS based data logging.
  3. GPRS and GPS application.
  4. Home automation.
  5. Health monitoring.
  6. Agriculture automation.
  7. Vehicle tracking.
  8. Remote monitoring and controlling.
  9. GPRS based Weather report logging.
  10. GSM GPRS based Security alert.
  11. GPRS based remote terminal for file transfer.
  12. IVRS.
  13. Bulk SMS sending etc.

Specifications and Features:

  1. Quad-Band 850/900/1800/1900MHz.
  2. RS232 interface for direct communication with computer or MCU kit.
  3. Configurable baud rate.
  4. ESD Compliance.
  5. With slid in SIM card tray.
  6. With Stub antenna and SMA connector.
  7. Input Voltage: 12V DC.
  8. High-quality PCB FR4 Grade with FPT Certified.
