The PDC004-PD Decoy Module operates on a 9V DC input, and its primary function is to simulate the negotiation process typically seen in USB Power Delivery systems. It mimics the presence of a compatible PD device, allowing engineers and technicians to test power delivery systems, troubleshoot issues, or protect devices from power surges or incorrect voltage levels.

This module is compact and easy to integrate into power systems, providing a low-cost solution for testing and protection applications. It’s equipped with basic safety features such as overvoltage and overcurrent protection to prevent damage to the system or connected devices. The PDC004-PD is ideal for applications in USB PD development, power distribution systems, and device protection where power negotiation needs to be simulated or tested without drawing actual power.

Features:

1. 9V Operation: The module operates at a 9V DC power input, making it suitable for use in systems that require low-voltage power delivery and protection.
2. Power Delivery (PD) Decoy: The decoy module simulates the presence of a PD-compatible device. This is useful for testing, protecting against power surges, or enabling certain devices to appear as if they are negotiating for power delivery.
3. Simulates USB Power Negotiation: The module can mimic the power negotiation process typically found in USB Power Delivery systems, without actually providing power to connected devices. This allows it to be used as a decoy in various testing and safety applications.
4. Overvoltage/Overcurrent Protection: Often integrated with basic safety features, the module may provide overvoltage and overcurrent protection to prevent damage to the system or components.
5. Compact Design: Designed to be small and lightweight, the module can be easily integrated into power delivery systems without taking up much space or adding significant weight.
6. Ease of Use: Typically designed for plug-and-play use, it simplifies testing and protection processes, reducing setup complexity.

Package Includes:

1 x PDC004-PD PD decoy module 9V
