6895ba3f53490996f99bc507 LBCX2810.5-H202-LANBOO-28*10.5mm PC Rocker Switch Red(DC 5-24V,20-2NO) https://www.componentstores.com/s/59c9e4669bd3e7c70c5f5e6c/6895ba4053490996f99bc509/r165297.png

The rocker switch 16A 28mm*10.5mm has become a popular choice of power switch in the fields of home appliances, office equipment, etc., with its multiple benefits such as high capacity, durability, standard size, high-quality materials, well-known brand certification and customized options. The rated load is up to 16A, which can meet the on-off needs of larger power equipment.
Some products, such as small-capacity non-sealed rocker switches, have a long life of up to about 50,000 times, ensuring stability and reliability for long-term use. The standard opening size of 28mm*10.5mm is convenient for users to install according to the device panel without additional processing or adaptation. The one-touch installation design makes the installation process simpler and faster. The panel is usually made of metal (such as brushed aluminum) to ensure the durability and good conductivity of the switch. The use of high-quality copper parts, such as copper parts in electronic switch sockets, ensures smooth current flow, reduces heat, and further improves product quality. With an indicator light, the luminous color can be selected in red or green, which is convenient for users to observe the on-off status of the switch. The luminous voltage is consistent with the switch voltage, and the optional range is wide to meet the different needs of users.  LANBOO p202406291358443d883

Specifications:

  1. Installation hole diameter: 28mm * 10.5mm
  2. Product number: LBCX2810.5
  3. Panel color: J-gold, Y-silver, H-black
  4. Operation type: self-locking(Latching)
  5. Gear position: 2 Gear position
  6. LED luminous color: R-red, G-green, custom :B-blue, Y-yellow, W-white
  7. LED voltage: 5-24V, 220V, custom:3-8V, 25-48V, 110V, AC/DC universal
  8. Border material: PC-Plastic
  9. Resistive load: AC-15:110V/250V:16A DC-13:12V/24V/36V:16A
  10. Contact resistance: AC-15:110V/220V:4A DC-13:110V:4A
  11. Push switch life: 200,000 times
  12. LED rated current: ≤24V,≤20mA:>24V,≤10mA
  13. LED life: >50000h

Package Includes:

1 x LBCX2810.5-H202-LANBOO-28*10.5mm PC Rocker Switch Red(DC 5-24V,20-2NO)

 TT-RB-R165297
in stock INR 151
1 1

LBCX2810.5-H202-LANBOO-28*10.5mm PC Rocker Switch Red(DC 5-24V,20-2NO)

Sku: TT-RB-R165297
Be the first to review this product
₹151
Add to Cart Buy Now
Sold By: tenettech
Features
  • Shipping in 10-12 Working Days

Description of product

The rocker switch 16A 28mm*10.5mm has become a popular choice of power switch in the fields of home appliances, office equipment, etc., with its multiple benefits such as high capacity, durability, standard size, high-quality materials, well-known brand certification and customized options. The rated load is up to 16A, which can meet the on-off needs of larger power equipment.
Some products, such as small-capacity non-sealed rocker switches, have a long life of up to about 50,000 times, ensuring stability and reliability for long-term use. The standard opening size of 28mm*10.5mm is convenient for users to install according to the device panel without additional processing or adaptation. The one-touch installation design makes the installation process simpler and faster. The panel is usually made of metal (such as brushed aluminum) to ensure the durability and good conductivity of the switch. The use of high-quality copper parts, such as copper parts in electronic switch sockets, ensures smooth current flow, reduces heat, and further improves product quality. With an indicator light, the luminous color can be selected in red or green, which is convenient for users to observe the on-off status of the switch. The luminous voltage is consistent with the switch voltage, and the optional range is wide to meet the different needs of users.  LANBOO p202406291358443d883

Specifications:

  1. Installation hole diameter: 28mm * 10.5mm
  2. Product number: LBCX2810.5
  3. Panel color: J-gold, Y-silver, H-black
  4. Operation type: self-locking(Latching)
  5. Gear position: 2 Gear position
  6. LED luminous color: R-red, G-green, custom :B-blue, Y-yellow, W-white
  7. LED voltage: 5-24V, 220V, custom:3-8V, 25-48V, 110V, AC/DC universal
  8. Border material: PC-Plastic
  9. Resistive load: AC-15:110V/250V:16A DC-13:12V/24V/36V:16A
  10. Contact resistance: AC-15:110V/220V:4A DC-13:110V:4A
  11. Push switch life: 200,000 times
  12. LED rated current: ≤24V,≤20mA:>24V,≤10mA
  13. LED life: >50000h

Package Includes:

1 x LBCX2810.5-H202-LANBOO-28*10.5mm PC Rocker Switch Red(DC 5-24V,20-2NO)
